Welded Mesh Fence
1):Height: 0.63m-3.0m
2):Width: 2.0m,2.2m,2.5m,3.0m(custom height and width is available)
3):Hole Opening: 50mmX50mm,50mmX100mm,50mmX150mm,50mmX200mm etc.
4):Wire Thickness: 3mm-8mm
5):Material: Low Carbon Steel Wire, Galvanized Wire
6):Finished: Electric Galvanized, Hot Dipped Galvanized, Polyester Painting,PVC Coated.
+86 15552138899
+86 15552138899
admin@globaltopsteel.com
Contact Us

◉ Product Details


Welded Wire Mesh Panels:

1):Height: 0.63m-3.0m
2):Width: 2.0m,2.2m,2.5m,3.0m(custom height and width is available)
3):Hole Opening: 50mmX50mm,50mmX100mm,50mmX150mm,50mmX200mm etc.
4):Wire Thickness: 3mm-8mm
5):Material: Low Carbon Steel Wire, Galvanized Wire
6):Finished: Electric Galvanized, Hot Dipped Galvanized, Polyester Painting,PVC Coated.

Fence Post:

1): peach post: 100mmX70mm,60mmX90mm,50mmX70mm

2): Square post: 60mmX40mm,60mmX60mm,60mmX80mm,80mmX80mm

3): Round post: 40mm-80mm
4): Thickness: 0.8mm-1.5mm
5): Length: On Request(Normal 0.65m-4m)
6): Finished: Hot Dipped Galvanized, electro galvanized,Polyester Painting(different colour)

Accessories of Welded Wire Fence:

1): Plastic Cap: Including Plastic Cap
2): Single Arm Or Double Arm: On Request
3): Tension Wire Or Barbed Wire: On Request
4): Concertina Razor Wire: On Request
5): Bolts & Nuts: According to Need


Specification List of Welded Wire Mesh:
OpeningWire Diamete【BWG】
In inchIn Metric Unit(mm)
1/4 x 1/46.4mm x 6.4mm22,23,24
3/8 x 3/810.6mm x 10.6mm19,20,21,22
1/2 x 1/212.7mm x 12.7mm16,17,18,19,20,21,22,23
5/8 x 5/816mm x 16mm18,19,20,21,
3/4 x 3/419.1mm x 19.1mm16,17,18,19,20,21
1 x 1/225.4mm x 12.7mm16,17,18,19,20,21
1-1/2 x 1-1/238mm x 38mm14,15,16,17,18,19
1 x 225.4mm x 50.8mm14,15,16
2 x 250.8mm x 50.8mm12,13,14,15,16
Technical Note:
1. Standard roll length: 30m;width: 0.5m to 1.8m
2. Special sizes available at request
3. Packing: in waterproof paper in rolls. Custom packing available at request.


PVC Coated Welded Mesh:
OpeningWire Diamete【BWG】
In inchIn Metric Unit(mm)
1/2 x 1/212.7mm x 12.7mm16,17,18,19,20,21
3/4 x 3/419mm x 19mm16,17,18,19,20,21
1 x 125.4mm x 25.4mm15,16,17,18,19,20
Technical Note:
1. Standard roll length: 30m;width: 0.5m to 1.2m
2. Special sizes available at request
3. Packing: in waterproof paper in rolls. Custom packing available at request.
